Descriere

MODEL 2508 (ESP) 2510 2512
Driver Size 8″ 10″ 12″
Watts RMS 400 – 800 400 – 800 400 – 800
Peak Power 3200 3200 3200
VCD 2.5 2.5 2.5
Impedance D2 / D4 D2 / D4 D2 / D4
Piston Dia – in 7 8 1/2 10
Fs – Hz 47.78 33.65 31.63
Qms 6.07 7 7.315
Qes 0.98 0.8424 0.9003
Qts 0.84 0.7519 0.8016
Vas – liters 2.07 16.987 43.551
Xmech – mm 57 57 57
Xmax – mm 17 17 17
Frame OD – in 9 1/16 10 5/8 12 11/16
Frame OD w/Gasket – in 9 1/4 10 13/16 12 13/16
Mounting Diameter – in 8 9 3/8 11 3/16
Mounting Depth – in 6 7/16 6 1/2 6 7/8
Motor Diameter – in 6 3/8 6 3/8 6 3/8
Motor Depth – in 2 15/16 2 15/16 2 15/16
Woofer Displacement – cu ft 0.08 0.1 0.12
Sealed Enclosure – cu ft N/A N/A N/A
Ported Enclosure – cu ft 0.75 – 1.25 1.25 – 1.5 1.75 – 2.75
Shipping Weight – lbs 20 22 25
