MODEL 2008C (ESP) 2010A 2012A
Driver Size 8″ 10″ 12″
Watts RMS 200 – 600 200 – 500 200 – 500
Peak Power N/A N/A N/A
VCD 2.5 2.5 2.5
Impedance D2 / D4 D2 / D4 D2 / D4
Piston Dia – in 7 8 1/2 10
Fs – Hz 28.93 29.61 26.92
Qms 5.03 5.114 5.388
Qes 0.68 0.797 0.790
Qts 0.6 0.690 0.689
Vas – liters 19.44 20.610 57.730
Xmech – mm 57 57 57
Xmax – mm 17 17 17
Frame OD – in 9 1/16 10 5/8 12 11/16
Frame OD w/Gasket – in 9 1/4 10 13/16 12 13/16
Mounting Diameter – in 8 9 3/8 11 3/16
Mounting Depth – in 6 7/16 6 1/2 6 7/8
Motor Diameter – in 6 3/8 6 3/8 6 3/8
Motor Depth – in 2 15/16 2 15/16 2 15/16
Woofer Displacement – cu ft 0.08 0.1 0.12
Sealed Enclosure – cu ft 0.5 – 1.0 0.4 – 0.8 0.5 – 1.0
Ported Enclosure – cu ft 0.75 – 1.25 1.25 – 1.50 1.75 – 2.75
Shipping Weight – lbs 20 21 24
